Banana split for maximum hydrogen production


Friday, 28 January, 2022


Banana split for maximum hydrogen production

Scientists at Ecole Polytechnique Fédérale de Lausanne have developed a way to maximise hydrogen yields from biowaste, within a few milliseconds. The method uses rapid photo-pyrolysis to produce hydrogen gas and solid conductive carbon from banana peels.

Biomass gasification

There are currently two main methods for converting biomass into energy: gasification and pyrolysis. Gasification puts solid or liquid biomass at temperatures around 1000°C, converting it into gas and solid compounds; the gas is called ‘syngas’ while the solid is ‘biochar’.

Syngas is a mix of hydrogen, methane, carbon monoxide and other hydrocarbons, and those are what are used as biofuel to generate power. On the other hand, biochar is often regarded as a solid carbon waste, although it can be used in agriculture applications.

Biomass pyrolysis

The other method, biomass pyrolysis, is similar to gasification except that biomass is heated at lower temperatures, between 400–800°C and at pressures up to 5 bar in an inert atmosphere. There are three types of pyrolysis: conventional, fast and flash pyrolysis. Out of all three, the first two take the longest time, and have the most char production.

Flash pyrolysis takes place at 600°C and produces the most syngas and has the lowest residence time. Unfortunately, it also needs specialised reactors that can handle high temperatures and pressures.

Banana split to maximise yields

Now, scientists led by Professor Hubert Girault at EPFL’s School of Basic Sciences have developed a new method for biomass photo-pyrolysis that produces not only valuable syngas, but also a biochar of solid carbon that can be repurposed in other applications. The work is published in Chemical Science.

The method performs flash light pyrolysis using a Xenon lamp, commonly used for curing metallic inks for printed electronics. Girault’s group has also used the system in the last few years for other purposes, like synthesising nanoparticles.

The lamp’s white flash light provides a high-power energy source as well as short pulses that promote photo-thermal chemical reactions. The idea is to generate a powerful flash light shot, which the biomass absorbs and which instantaneously triggers a photothermal biomass conversion into syngas and biochar.

This flashing technique was used on different sources of biomass: banana peels, corn cobs, orange peels, coffee beans and coconut shells, all of which were initially dried at 105°C for 24 hours and then ground and sieved to a thin powder. The powder was then placed in a stainless-steel reactor with a standard glass window at ambient pressure and under an inert atmosphere. The Xenon lamp flashes, and the whole conversion process is over in few milliseconds.

“Each kg of dried biomass can generate around 100 litres of hydrogen and 330 g of biochar, which is up to 33 wt% of the original dried banana peel mass,” said Bhawna Nagar, who worked on the study. The method also had a positive calculated energy outcome of 4.09 MJ per kg of dried biomass.

What stands out in this method is that both of its end products, hydrogen and solid-carbon biochar, are valuable. The hydrogen can be used as green fuel, while the carbon biochar can either be buried and used as a fertiliser or it can be used to manufacture conductive electrodes.

“The relevance of our work is further heightened by the fact that we are indirectly capturing CO2 stores from the atmosphere for years,” Nagar said. “We have converted that into useful end products in no time using a Xenon flash lamp.”

Image credit: ©stock.adobe.com/au/nataliazakharova
